CNC computer screw machine--WSD20-5A
- Wire Diameter: Ø0.2-Ø2.0mm
- Handle length: ≤45*50mm
- Spoolmaximum working stroke: 40mm
- Spool minimal instruction value: 0.1°
- Spool maximum command value: ±99turns±359.9°
- Cam shaft set value: 0.1°-359.9°
We're here to help:
Easy ways to get the answers you need.
| Technical parameters | ||||
| Model | WSD20-5A | |||
| Wire Diameter | Ø0.2-Ø2.0mm | |||
| Handle length | ≤45*50mm | |||
| Spoolmaximum working stroke | 40mm | |||
| Spool minimal instruction value | 0.1° | |||
| Spool maximum command value | ±99turns±359.9° | |||
| Cam shaft set value | 0.1°-359.9° | |||
| Axis minimum setting value | 0.01mm | |||
| Lifting shaft set value | 40mm | |||
| Output per minute | 0-120pcs | |||
| Wire feeding servo | 2.7kw | |||
| Cam servo | 2.7kw | |||
| Winding servo | 1.5kw | |||
| Traverse servo | 1.5kw | |||
| Power consumption | 5.7kw | |||
| Size | 1280*1180*1650 | |||
| Machine weight | 0.5T | |||
